PE1RDP's Avatar

PE1RDP

@pe1rdp.bsky.social

HAM radio Volunteer to build the peripherals of the regional repeaters PI2EHV PI3EHV PI6EHV and PI6EHN Trying to learn CW. Radioplanner at Ericsson.

233 Followers  |  137 Following  |  280 Posts  |  Joined: 18.11.2024  |  2.04

Latest posts by pe1rdp.bsky.social on Bluesky

Post image Post image Post image

Doing some radio experiments with #meshcore on #868MHz
Transceiver is Heltec v4 and #antenna a 8dBi vertical.
Just placed this #repeater in the mast.

#hamradio #hamr #AmateurRadio #prep #EmergencyResponse

10.12.2025 15:54 β€” πŸ‘ 5    πŸ” 1    πŸ’¬ 0    πŸ“Œ 0

On the Dutch teletext, even hamradio dx expedition news was announced. And the correct answers of the ham exam. But that was in the 80s.

01.12.2025 09:32 β€” πŸ‘ 1    πŸ” 0    πŸ’¬ 1    πŸ“Œ 0
Video thumbnail

QRV in cq ww cw contest.
At Saturday under callcall pi4kar.

#hamradio #hamr #AmateurRasio #amateur #radio #antenna #HF #contest #cw #morse #weekend #Saturday #Sunday

29.11.2025 23:53 β€” πŸ‘ 3    πŸ” 0    πŸ’¬ 1    πŸ“Œ 0
Video thumbnail

QRV in cqww cw contest.
This morning from clubstation PI4KAR and now from home.

#hamradio #hamr #AmateurRadio #contest #cw #morse #HF

29.11.2025 14:39 β€” πŸ‘ 4    πŸ” 0    πŸ’¬ 0    πŸ“Œ 0
Post image Post image Post image Post image

Connected a BME280 sensor to the #Meshcore transceiver Heltec V4.
SDA goes to GPIO 17
SCL goes to GPIO 18
Vcc = 3.3v

Needs some calibration πŸ˜„

#hamradio #hamr #AmateurRadio #868MHz #prepping #Weather #temperature #pressure #humidity

23.11.2025 15:38 β€” πŸ‘ 2    πŸ” 1    πŸ’¬ 0    πŸ“Œ 0

Wow! That are unforgettable QSOs confirmed by a nice card with beautiful stamps.

16.11.2025 11:36 β€” πŸ‘ 1    πŸ” 0    πŸ’¬ 0    πŸ“Œ 0
Post image Post image Post image Post image

Playing again with 868MHz #meshcore #mesh network.

The #swr plot of the stock #antenna of my Heltec t114 and a few-minutes-build GP.

#hamradio #hamr #AmateurRadio #measurement #DIY

16.11.2025 09:19 β€” πŸ‘ 8    πŸ” 2    πŸ’¬ 0    πŸ“Œ 0

No FT8 those days.
The bands were filled with ssb, cw and some computer modes (rtty, amtor, pactor, ax25, sstv).
And, FM and AM on 10m on a daily base.

16.11.2025 07:12 β€” πŸ‘ 0    πŸ” 0    πŸ’¬ 1    πŸ“Œ 0
Post image

Almost no rain here in the Netherlands.
This pool of water should fully filled this time the year.

13.11.2025 17:17 β€” πŸ‘ 3    πŸ” 0    πŸ’¬ 1    πŸ“Œ 0

Indeed. This is homebuild but it is also available in commercial webshops as "qrm eliminator X-phase".
Only worth the money if you can place the phase antenna close to the source.

13.11.2025 13:06 β€” πŸ‘ 1    πŸ” 0    πŸ’¬ 0    πŸ“Œ 0
Video thumbnail

Local #interference makes #reception below 5 MHz impossible.
But this solution with a miniwhip #antenna and mixing this signal out of phase, the #QRM is almost gone.

#hamradio #hamr #AmateurRadio #residential #solution #HF #shortwave

13.11.2025 09:54 β€” πŸ‘ 6    πŸ” 0    πŸ’¬ 1    πŸ“Œ 0

The Social media those days.

10.11.2025 04:19 β€” πŸ‘ 0    πŸ” 0    πŸ’¬ 0    πŸ“Œ 0
Video thumbnail

March 3th 1980, it was legal to use #CB #radio in the #Netherlands.

In the first weeks, more than 300000 licences were sold but only 22 channels were available.

The result: very crowded channels.
Hear the mess of #channel 14.

#hamradio #hamr #AmateurRadio
#antenna #FM

09.11.2025 19:45 β€” πŸ‘ 5    πŸ” 0    πŸ’¬ 1    πŸ“Œ 0

"At the top of the dial".

During the English lessons at school, we had to learn poems. I did choose the songtext London Calling.

06.11.2025 20:18 β€” πŸ‘ 1    πŸ” 0    πŸ’¬ 1    πŸ“Œ 0

On AliExpress. Last week around 22 euro

02.11.2025 08:27 β€” πŸ‘ 0    πŸ” 0    πŸ’¬ 0    πŸ“Œ 0
Video thumbnail

Waterfall on HF
No conditions at this moment.

#hamradio #hamr #AmateurRadio #SI4732

01.11.2025 13:31 β€” πŸ‘ 4    πŸ” 0    πŸ’¬ 0    πŸ“Œ 0

At AliExpress for about 20 euros last week

01.11.2025 13:30 β€” πŸ‘ 0    πŸ” 0    πŸ’¬ 0    πŸ“Œ 0
Video thumbnail

#testing the #waterfall #display

Can be activated at backlight 32 or 33 and use ETM mode.
By turning and pressing the #VFO button you can enter the #station showed on the waterfall.

#hamradio #hamr #AmateurRadio #radio #SI4732 #antenna #SDR
#firmware

01.11.2025 13:29 β€” πŸ‘ 9    πŸ” 1    πŸ’¬ 3    πŸ“Œ 0
Video thumbnail

With this mod, you will have a #RTTY #decoder
New is the terminal #display to have a larger read back window.

#conditions are bad today but here is a small #demo with Pinneberg #weather #station

#hamradio #hamr #AmateurRadio #antenna #tadio #SI4732 #WX
#HF #shortwave

01.11.2025 13:28 β€” πŸ‘ 5    πŸ” 1    πŸ’¬ 0    πŸ“Œ 0
Post image Post image

Two weeks ago, during #JOTA , someone was really impressed by the #SI4732 #mini #radio so I give my device to him.

I bought a new one (V3) and the #hardware #mod for #RTTY decoder is already made.

Playtime.

#hamradio #hamr #AmateurRadio #YOUTH #scouting

01.11.2025 12:10 β€” πŸ‘ 3    πŸ” 1    πŸ’¬ 1    πŸ“Œ 0

No, these were the dishes of PA3CSG.

The solid dish is now at PA3DZL and the other (8m) dish has been moved to OK1TEH.

Geert, PA3CSG, was forced to stop EME because of RFI from commercial users.

29.10.2025 14:04 β€” πŸ‘ 0    πŸ” 0    πŸ’¬ 0    πŸ“Œ 0
Post image Post image Post image Post image

QRV as PI6SBW/J at the #JOTA #JOTI 2025
Giving the #children a great #weekend

#hamradio #hamr #AmateurRadio #scouting #Eindhoven #antenna #children #volunteer #volunteering #transceiver

18.10.2025 22:47 β€” πŸ‘ 8    πŸ” 1    πŸ’¬ 0    πŸ“Œ 0

That's good news. The downside of scu-lan10 was lack of cw.
Solved here with 2x arduino (one at laptop side and other at transceiver side).

16.10.2025 07:59 β€” πŸ‘ 1    πŸ” 0    πŸ’¬ 1    πŸ“Œ 0

Cheap LED 🀬

08.10.2025 18:56 β€” πŸ‘ 0    πŸ” 0    πŸ’¬ 1    πŸ“Œ 0

Misschien de verleden tijd van kwantum?

07.10.2025 10:33 β€” πŸ‘ 0    πŸ” 0    πŸ’¬ 0    πŸ“Œ 0

Yes, we will at least make a note in the VHF UHF part.

06.10.2025 10:19 β€” πŸ‘ 1    πŸ” 0    πŸ’¬ 0    πŸ“Œ 0

You need line of sight indeed.

05.10.2025 14:44 β€” πŸ‘ 1    πŸ” 0    πŸ’¬ 0    πŸ“Œ 0

Thank you

05.10.2025 14:16 β€” πŸ‘ 0    πŸ” 0    πŸ’¬ 1    πŸ“Œ 0
Post image Post image Post image Post image

During the UHF and up #contest we made some QSO on 122 GHz (wavelength is 2.5mm) between #Netherlands and #Germany
RF power was only 0.5 mW (-3dBm) in FM F3E.
#QTH is JO21XC
Also #10GHz experiments

#hamradio #hamr #AmateurRadio #radio #SHF #122GHz #antenna #Microwave #dish

05.10.2025 12:12 β€” πŸ‘ 12    πŸ” 0    πŸ’¬ 2    πŸ“Œ 0

December: the period that those outdoor LED Christmas lights making it even worse.

04.10.2025 18:36 β€” πŸ‘ 0    πŸ” 0    πŸ’¬ 1    πŸ“Œ 0
