Eduart Misiraj

Seg Dreamcast RGB Scart cable build
- Csync
- 15khz
- 1.5m individually shielded cable
- low ESR electrolytic capacitors
- pcb board on scart plug

Mega Drive 1 RGB Scart cable
- CSync
- 4ft double shielded cable
- good quality 8pin din connector
- stereo
- low esr, low profile polymer capacitors

Mega Drive 2 RGB Scart cable
- CSync
- 4ft double shielded cable
- high-quality 9pin mini din connector
- resistors on din plug for better video/audio
- low esr, low profile electrolytic capacitors

RGB Scart cable order build
- Mega Drive 1
- Mega Drive 2
⬇️ details
#retro #gaming #RETROGAMING

Never ceases to amaze me how crisp and clean of an image you can get from this 40+ year old machine! Captures taken with EM-Modshop SNES Csync cable (
@misirajeduart.bsky.social ) and RetroTink 4K/Elgato 4KX
-Adventure Island 2
-Dragon Warrior IV
-Golgo 13
-Operation Wolf

🧵4/4

Screenshots

Sega Genesis 2 RGB Scart cable
- CSync
- 1.5m double shielded cable
- resistors on the connector side for better video/audio
- high-quality 9pin mini din connector
- low ESR, low profile electrolytic capacitors

Got some screen captures using a MegaDrive 2 RGB Scart cable from EM-Modshop ( @misirajeduart.bsky.social ) and the Retrotink 4K / Elgato 4KX!
- Mega Man Wily Wars
- Water Margin
- Aladdin
- Virtua Fighter 2

🧵3/3

PAL Gamecube RGB Scart cable
- CSync (sync stripper)
- 1.5m double shielded cable
- low esr, low profile electrolytic capacitors

Sega Saturn RGB Scart cable
- Sync on Luma
- NTSC & PAL compatible
- 1.5m double shielded cable
- high-quality 10pin mini din connector for stock and new Saturn ports

Sega Dreamcast RGB Scart cable
- CSync
- 1.5m double shielded cable
- low esr, low profile electrolytic capacitors

NEO GEO Aes RGB Scart cable
- CSync
- Stereo lead
- 1.5m(5ft.) double shielded cable
- pcb board on scart plug
- good quality 8pin din connector
#rgb #games #retro #retrogaming

RGB Scart cables built during the past few days
- Neo Geo AES stereo
- Nintendo PAL Gamecube
- Sega Dreamcast
- Sega Saturn

Got a sweet new RGB Scart cable from @misirajeduart.bsky.social to use with my modded Virtual Boy!

It's a custom SNES cable with 3.5mm Stereo audio connector to grab audio from the headphone jack on the VB and pass it through to the CRT / Retrotink

4K screenshots below 👇

Sega Dreamcast RGB Scart cable
- Csync
- polymer capacitors
- 15khz
- 1.5m double shielded cable

This is the dumbest thing I've read in a long while

Mister fpga VGA to RGBs Scart cable
- 1.5m double shielded cable
- stereo
- 470ohm resistor on sync line
- 15khz

Well, what have we here? A package from a certain @MisirajEduart, the cable wizard! These will pair up with the 3 systems a friend asked to procure and now that they are here, I can run the final validation.
Let's look at some pictures. 🧵👇
#RETROGAMING

PC Engine RGB Scart cable
- for 8pin din #RGB moded Pc Engine systems only
- 1.5m double shielded cable
- Sync on Composite
- Good quality 8pin din connector
- pcb board on scart plug
#retro #pcengine #gaming

Screenshots captured from the 64BP mod using EM-Modshop ( @misirajeduart.bsky.social ) Saturn CSYNC cable on my RetroTink 4K and Elgato 4KX!

- Rayman
- Atari Karts
- Wolfenstein 3D
- Iron Soldier 2

🧵3/3

SNK NEO-GEO RGB Scart cable build
- 1.5m double shielded cable
- Mono audio
- For AES, CD, CDZ

Screenshots captured using EM-Modshop ( @misirajeduart.bsky.social ) SNES CSYNC cable on the RetroTink 4K and Elgato 4KX!

- Secret Of Evermore
- Prehistoric Man
- Donkey Kong Country 2
- Dracula X

🧵4/4

Playstation 2/3 RGB Scart cable
- 15/33khz CSync
- 480p/1080i resolution for games that support them
- Lightgun support
- 1.8m(6ft.) Individually shielded cable

Sega Saturn Composite & S-Video combo cable build with some high quality individually and outer shielded cable.

They are pretty good. But small so you can't cut very thick or hard wire with them. Perfect for cutting wires when building cables or modding systems.

I would suggest getting a few different pairs for different jobs and size

Got a pair of Engineer Micro Nippers NS-06
Flush cutting
Adjustable handle
ESD safe handle
Best ones you can get 😁

Screenshots captured with the incredible Sega Saturn RGB Scart cables from EM-Modshop ( @misirajeduart.bsky.social ) and via my RetroTink 4K and Elgato 4KX!

- Darius Plus
- Madou King Granzort
- Ghouls 'n Ghosts
- 1941 Counter Attack

🧵3/3

Sega Dreamcast RGB Scart
- individually shielded 1.5m cable
- polymer capacitors
- csync

Sega Mega Drive 1 RGB Scart
- 1.5m individually shielded wire
- csync
- polymer capacitors
- stereo

Binge buying Playstation 3 and Xbox360 games lately. They cost like a dime nowadays, so perfect time to get this. Even PS4 isn't that expensive. My collection is growing 😁
